30l Chemic Trumid Dun Port Star Star Barking igwe

Model:KGH30D

Ezubere ya na nchekwa kemịkalụ gị, Kgh30D bụ ihe ngosi kemịkal dị na 1l na-agagharị na igwe dị elu 15L na-egbu egbu. Ezigbo maka igwe na-arụ ọrụ 25l na-arụ ọrụ, dị ka 25l na 30l Chemical Drums, ọ na-ewere oge na-agụchi obi na ego nchekwa na efu ị nwere ike ịtụkwasị obi. Ka anyị tinye gị elu - kpọtụrụ anyị iji mepụta usoro a na-ahazi taa!

Olu: 30lIbu ibu: 28.5T

Zipu ajụjụ

Nkọwa ngwaahịa Specification Application

Zuru okè maka ịmepụta 25l na 30L Chemical Droms, igwe a na-eme ka ọ dị agụụ na ọnụ ahịa - arụmọrụ, na-eme ọ bụ ihe dị mkpa maka usoro ọ bụla. Ya na ezigbo ihe na nkenke, KGH30D 30L Chemic uw uw onye ọrụ na-ebugharị arụmọrụ na-agbanwe agbanwe agbanwe mgbe ị na-enyere gị aka IKWU EGO NA-EGO NA-EGO. Gị na anyị na onye gị na ha nọ Mepụta ngwọta a kwadoro nke dabara na mkpa gị ma mee ka ị na-akwalite gị ike nrụpụta.

Atụmatụ na uru

Bulite ụdị nrụpụta gị na-aga n'ihu igwe na-aga n'ihu na-aga n'ihu igwe, nke emere maka arịa ruru 30l. Site na nhazi mgbanwe (2, 3, ma ọ bụ 4 isi okwu dị ukwuu), ọ na-ejikwa obere akpa 30l na barel 30l, na-ejide oke mmepụta ma na-agbanwe agbanwe.
Ezigbo maka ngwa dị ka shampoo, ịsacha akwa, na nkwakọ ngwaahịa, igwe a na-anapụta mmepụta dị elu na-anọgide na-adị elu. Enyemaka ya na arụmọrụ dị mma na-enyere aka belata mmepụta ma nwekwuo mmepụta, na-eme ka ọ dị oke ọnụ ahịa nke na-abawanye nlọghachi gị na itinye ego.

Specifications

serial number	Material PE、PP、PVC、PA...	High speed movement mode(curved arm)
serial number	Material PE、PP、PVC、PA...	Machine model:KGH30D
Specifications
1	Max container capacity	30L
2	Output(dry Cycle)	450 PC/HR x 2 PC/HR
3	Machine Dimension(L×W×H)	5.8 M x 4.2 M x 3.8 M
4	Machine weight	28.5T
Clamping Unit
1	Clamping force	300 KN
2	Mold platen size(W×H)	630 MM x680 MM
3	Platen openingstroke	450 MM -1000 MM
4	Platen moving stroke	750 MM
5	Max mold size(W×H)	730 MM -680 MM
6	Mold thickness	480 MM -580 MM
Power
1	Servooil pump motor power	22 KW
2	Servo pump displacement	200 L/MIN
3	Blowpressure	0.6 Mpa
4	Air consumption	1.8 M³/MIN
5	Cooling water pressure	0.2 Mpa - 0.3 Mpa
6	Water consumption	180 L/min
7	Average energy consumption	70 KW -80 KW
Extruder unit
1	Screw diameter	100 MM
2	Screw L/D ratio	25 L/D
3	Melting capacit for HDPE	300 Kg/hr
4	Number of heating zone	5 ZONE
5	Screw heating power	20 KW
6	Screw fanpower	0.9 KW
7	Extruder motor power	90 KW
Die head
1	Number of heating sections	3 * 8 ZONE
2	Heating power	6.5 KW
3	Maxdie-pin diameter	220 MM
4	Accumulator capacity	280 MM
5	(PE)Accumulator weight	170 MM
